Agricultural measuring station with 8 probes

Agricultural measuring station with 8 probes

€769.00 (tax incl.) (€640.83 VAT excl.)
Delivery in 1 to 5 days in Europa

Auxiliary station for adding temperature, soil moisture, and leaf wetness sensors to your Vantage Pro 2 weather station. Includes 4 Wattermark 6440 sensors and 4 6470 temperature sensors.

Reference
6345CSOV
Available (3 Items)

The 6345CSOV is a special agricultural weather station for measuring leaf wetness and soil temperature/humidity. The 6345CSOV agricultural weather station is compatible with the Vantage pro 2 series of weather stations using the 868.0 - 868.6 MHz frequency, the range is 300 meters at sight. You can use the 6345CSOV directly with a 6312EU LCD console, a 6316EU non-display Weather Envoy console, or a 6100EU WeatherLink Live Connector.

6345CSOV version: comes with 4 6440 and 4 6470 sensors.

The 6345CSOV Agricultural Weather Station comes with:

  • Radio transmitter 6345OV
  • 2 U-brackets + washers and nuts
  • 4 lag screws
  • 3 fixing clamps
  • 1 x 3V Lithium battery
  • 4 soil moisture probes - Ref: 6440
  • 4 soil temperature probes - Ref: 6470



Miscellaneous
Composition
plastiques PVC résistants aux UV
Measure
Soil Moisture ; Temperature ; Leaf Wetness
Power supply
panneau solaire, accumulateur 10F, pile de secours
Size
299 x 172 x 153 mm
Weight
1.7 kg
Operating temperature
-40° à +65°C
Backup power supply
pile Lithium 3V CR123 (non fournie)
Storage temperature
-45° à +70°C
Radio frequency
868.0 - 868.6 MHz FHSS, inférieur à 8mW
Wireless range
300m à vue, 60 à 120m avec des obstacles
Temperature
Units of measurement
°C, °F
Resolution
1
Accuracy
±0.5°C
Measuring range
-40° à +65° C
Measurement frequency
77 à 90 secondes
Wiring
4.6m, câble 22 AWG à enfouissement direct, dénudé et étamé
Soil moisture
Units of measurement
centibar
Resolution
1
Measuring range
0 à 200 cb
Measurement frequency
77 à 90 secondes
Wiring
4,6 m, câble bifilaire standard Watermark, dénudé et étamé
Measurement principle
Résistance électrique
Leaf wetness
Units of measurement
Indice
Accuracy
±0.5
Measuring range
0 à 15
Measurement frequency
46 à 54 secondes
Measurement principle
Résistance électrique
